Durable Aquaculture Ozone Generator 3g - 7g/h For Recirculating Aquaculture System RAS With CE

Durable Aquaculture Ozone Generator 3g - 7g/h For Recirculating Aquaculture System RAS With CE

  • High Light

    spa necessities ozone generator

    ,

    ozone generator for fish farm

  • Cooling Way
    Air Cooled
  • Ozone Output
    3g/h,5g/h,6g/h,7g/h
  • Gas Feed
    Air Source Or Outside Oxygen Source
  • Color
    Blue, Customized
  • Size
    355×215×310mm
  • Capacity (CFM)
    98%
  • Place of Origin
    China
  • Brand Name
    Netech
  • Model Number
    CH-BP
  • Minimum Order Quantity
    One unit
  • Price
    $ 290 - $ 340
  • Packaging Details
    Safe double carton package with foam inside for protection
  • Delivery Time
    2 to 3 working days after payment confirmed
  • Payment Terms
    L/C D/A D/P T/T Western Union Credit Card/ Paypal
  • Supply Ability
    3000 sets per month

Durable Aquaculture Ozone Generator 3g - 7g/h For Recirculating Aquaculture System RAS With CE

Ozone Generator 3g - 7g/h For Recirculating Aquaculture System RAS With CE





Quick details:



Time control 5-30 mins or continuously
Usage air and water purifier,remove odor,kill bacteria,vegetables washing,etc
Power supply 220V/110v 50/60Hz
Ozone output 3g/5g/6g/7g
Adjustable ozone 20%-100%
Warranty 12 months





Operations:


1. Before use this machine,put it in a stable flat place which can hold its weight.

2. Use the power equipped with the machine;

3. The machine use for air purification,firstly attach the silicone tube into the ozone outlet and then turn on the power;

4. Set the timer and then come out ozone, and put the tube into the room.

5. When use for room air purification, it requires nobody is present , after 30 minutes people can walk into the room.

6. If use for water treatment, the air stone should be attached into the silicone tube and put into the water.

7. Attention,the machine should be placed higher than the water, incase that the water reflux occur


(NOTE: The model NT-BP can use the outside oxygen source)



Specification :



Item Gas flow rate Ozone output Power Output gas tube Fuse Size NW
Model LPM G/Hr W mm A mm Kg
NT-BP3G 10 3 70 φ6 3 355×215×310 8.5
NT-BP5G 5 80 8.6

NT-BP

6G

15 6 100 8.7

NT-BP

7G

17 7 110 8.8



Noted:

1. Above ozone capacity were tested under oxygen source

2. Net weight will be 10% different for different plug.




Application:

1. All kinds of factories and enterprises clean and cleanion, food factory, beverage factory, mineral water factory, pharmaceutical factory, health products factory workshop, warehouse, packing material room, buffer room, locker room, food antisepsis etc.

2. Public places cleanion, clean, removing odor:Organs and units, school, nursery school, office, classroom, conference room, hall, restaurant, dormitory, recreation room, bathroom etc.

3.Warehouse and agriculturalproducts keep fresh and anti-corrosion:
Food, eggs, Chinese herbal medicine, fruits, vegetables, aquatic products, meat products, such as warehouse cleanion, clean, anticorrosion, preservation, remove residual pesticide, decomposition hormone.

4.Breeding industry clean, cleanion and deodorant:
Indoor chicken farm, pig farm, animal feed farm, aseptic inoculation and cultivation etc.

5.Archives and libraries: archives clean, mould proof, insect repellent, moth-proofing, etc.

6. Water treatment: tap water treatment, waste water treatment, waste water bleaching, color decoloration, reduce BOD and COD.

7. Waste air treatment: Odor removal, treatment aromatic hydrocarbon, Benzodiazepines etc.



Durable Aquaculture Ozone Generator 3g - 7g/h For Recirculating Aquaculture System RAS With CE 0

Durable Aquaculture Ozone Generator 3g - 7g/h For Recirculating Aquaculture System RAS With CE 1

Durable Aquaculture Ozone Generator 3g - 7g/h For Recirculating Aquaculture System RAS With CE 2

Domestic Utility Model : NO.2012 2 0273958.4



Durable Aquaculture Ozone Generator 3g - 7g/h For Recirculating Aquaculture System RAS With CE 3

Domestic Design : NO.2012 3 0010170. X





ABOUT US!



1.Having 10 years production experienced .We are trusty business partner.

2.Quality Controlled:Quality Control personnel check the quality at every stage

of production, from the incoming raw materials to the finished product.

3.NT-BP Production Capacity: 3000 pcs per month.

4.We have serial products: ozone tube ,UV water cleanrs, ozonegenerators, oxygen concentrators, protein skimmers, and filters, mixing pumps and other water or air treatment spare parts.

5.We supply OEM service according to customers' requests and give out professional suggestions.
