220V Ozone Generator Water Treatment Swimming Pools , Ozone Pool Treatment System

220V Ozone Generator Water Treatment Swimming Pools , Ozone Pool Treatment System

  • High Light

    ozone generator swimming pool

    ,

    ozone generator water treatment swimming pools

  • Commodity Name
    Water Ozonator, Ozone Water Purifier
  • Gas Feeding
    Air And Oxygen Feed
  • Voltage
    110V Or 220V
  • Ozone Output
    2G 3G 5G 6G 10G 15G 20G 30G
  • Ozone Generating Type
    Corona Discharge
  • Ozone Generator Type
    Ceramic Ozone Tube
  • Water Treatment
    Agriculture,hotels,vegetables,fruits,home, Food, Kitchen
  • Warranty
    1 Year
  • Place of Origin
    China
  • Brand Name
    ozocenter
  • Model Number
    CH-T
  • Minimum Order Quantity
    1
  • Price
    300-900USD
  • Packaging Details
    with froth in cartons or wooden case
  • Delivery Time
    3 to 5 days
  • Payment Terms
    paypal,western union,T/T,credit card
  • Supply Ability
    1000 per weeks

220V Ozone Generator Water Treatment Swimming Pools , Ozone Pool Treatment System


                                              Ozone Generator Water Treatment Swimming Pools 220V


1. Quick details
   Brand Name:                    ozocenter

Model Number:               CH-T

Certification:                    domestic
Ozone output way:          air cooling

Warranty:                        one year warranty
Adjustable rate:               20-100% adjustable ozone


Description

Gas source Oxygen
Oxygen flow rate 1-18LPM
Material Ceramic tube
Cooling Air cooling
Power supply 220V,50/60HZ
Commodity Ozone water system
Ozone output 2g/3g/5g/6g/10g/15g/20g
Size 360*260*610/400*300/770mm





how to use ?

1. Before use this machine, put it in a stable flat place which can hold its weight.

2. Use the power equipped with the machine;

3. The machine use for air purification, firstly attach the silicone tube into the

ozone outlet and then turn on the power;

4. Set the timer and then come out ozone, and put the tube into the room.

5. When use for room air purification, it requires nobody is present, after 30

minutes people can walk into the room.

6. If use for water treatment, the air stone should be attached into the silicone

tube and put into the water.

7. Attention,the machine should be placed higher than the water, incase that the water reflux occur.


Control panel:

Voltmeter, Ammeter, Switch, Timer,

Working light, Power light etc.


Timer: One or Two recycle working time


                                                                        CH-T

Item Unit                                                             CH-T
2G 3G 5G 6G 10G 15G 20G
Oxygen flow rate LPM 0.5~2 1~3 1.2~3 1.5~3.5 2.4~6 3.6~9 3~10
Ozone concentration Mg/L 28~50 28~65 32~60 28~56 32~60 32~60 38.9~42
Ozone output G/Hr 1.5~3.0 4~5.0 4.3~5.7 5.0~5.8 8.6~14.5 13~17 18.6~20
Power W 115 135 160 185 260 330 400
Air flow rate (Suggested) LPM 40~60 50~75 50~90
Compressed air pressure Mpa 0.025
Fuse of power supply A 3 5 5 5
Size cm 36×26×61 40×30×77
Net Weight kg 11.25 11.30 11.50 18 20 35
