Netech is proud of its extensive experience in the nautical industry and of its list of references which includes the most important Italian and International Shipyards. The success of Netech comes from a deep knowledge of the boats and of the onboard problems and from constant technical and experimental research in order to create systems that are suitable, efficient, easy to install and compatible with the technical realities of the boats.
Function:
It is used to destroy single celled organisms such as water borne bacteria and viruses. The cleanr is also used to control algae and to kill fungi and protozoa. Aqua Ultraviolet cleanrs are recommended for both fresh and salt water systems as well as ponds. The ultraviolet lamp emits a germicidal ray which alters or disrupts the DNA or RNA of targeted organisms such as algae, bacteria and protozoa. The Aqua ultraviolet cleanr works better on filtered water. Any debris in the water can inhibit UV transmission.
Feature:
0.1-2.7 T/ h water flow rate
9000-13000 hrs service life(Max)
adopts America NSF55 standard of “Ultraviolet microbial water treatment equipment” and domestic Ultraviolet cleanr industry standard for living and drinking water of CJ/T204-2000.
Internal & external polishing mirror chamber with high brightness for greatly improved UV intensity and clean effect.
Here are some solutions offered by Netech for the nautical sector:
▪ Removal of odors coming from the air vents of black water and gray water tanks;
▪ Purification and reclamation of freshwater in tanks;
▪ Elimination of odors due to stagnation in the bilges;
▪ Sanitation of UTA and Fancoils ducts as well as the air injected in the cabins;
▪ Environmental reclamation
Specification:
Model |
Water flow (T/Hr) |
Power (W) |
Size (mm) |
Water Input & Ouput Size |
Max Pressure (Mpa) |
NT-UV005G | 0.1 | 8 | 250×48×65 | 1/4″ | 0.8 |
NT-UV01G | 0.2 | 10 | 295×60×80 | 1/4″ | |
NT-UV02G | 0.5 | 14 | 370×60×80 | 1/2″ | |
NT-UV04G | 1 | 17 | 450×73×110 | 1/2″ | |
NT-UV06G | 1.3 | 23 | 520×73×110 | 3/4″ | |
NT-UV08G | 1.8 | 28 | 650×73×110 | 3/4″ | |
NT-UV12G | 2.7 | 40 | 950×73×110 | 1″ |
Model |
Water flow (T/Hr) |
Power (W) |
Size (mm) |
Water Input & Ouput Size |
Max Pressure (Mpa) |
NT-UV3T | 3 | 40×1 | 950×125×250 | 1″ | 0.8 |
NT-UV5T | 5 | 40×2 | 950×138×280 | 1.2″ | |
NT-UV8T | 8 | 40×3 | 950×170×310 | 1.5″ | |
NT-UV12T | 12 | 40×4 | 950×195×335 | 2″ | |
NT-UV15T | 15 | 40×5 | 950×195×335 | 2″ | |
NT-UV20T | 20 | 80×3 | 950×205×405 | 2.5″ | |
NT-UV25T | 25 | 80×4 | 950×275×465 | 2.5″ | |
NT-UV30T | 30 | 120×3 | 1250×275×545 | 3″ |
