UV Ozone Generator Parts For Shrimp Fish Pond Drinking Sea Water Treatment

UV Ozone Generator Parts For Shrimp Fish Pond Drinking Sea Water Treatment

  • High Light

    ozone accessories

    ,

    ozone generator tube

  • Water Flow Rate
    0.1-2.7 Ton / Hr
  • Material
    SS304 Or SS316L
  • Max Pressure
    0.8 Mpa
  • Sterilizing Rate Up
    99.99%
  • Warranty
    10 Years Warranty For Stainless Steel Housing, Other Components Are 1 Year
  • Application
    Koi Fish Pond Pool Drinking Water Trearment
  • Place of Origin
    Guangdong China
  • Brand Name
    Netech
  • Model Number
    NT-UV
  • Minimum Order Quantity
    1 set
  • Price
    For futher discussion
  • Packaging Details
    Safe double carton package with foam inside for protection
  • Delivery Time
    3-8 days after payment confirmed

UV Ozone Generator Parts For Shrimp Fish Pond Drinking Sea Water Treatment

UV Ozone Generator Parts For Shrimp Fish Pond Drinking Sea Water Treatment

Netech is proud of its extensive experience in the nautical industry and of its list of references which includes the most important Italian and International Shipyards. The success of Netech comes from a deep knowledge of the boats and of the onboard problems and from constant technical and experimental research in order to create systems that are suitable, efficient, easy to install and compatible with the technical realities of the boats.



Function:

It is used to destroy single celled organisms such as water borne bacteria and viruses. The cleanr is also used to control algae and to kill fungi and protozoa. Aqua Ultraviolet cleanrs are recommended for both fresh and salt water systems as well as ponds. The ultraviolet lamp emits a germicidal ray which alters or disrupts the DNA or RNA of targeted organisms such as algae, bacteria and protozoa. The Aqua ultraviolet cleanr works better on filtered water. Any debris in the water can inhibit UV transmission.


Feature:

0.1-2.7 T/ h water flow rate

9000-13000 hrs service life(Max)

adopts America NSF55 standard of “Ultraviolet microbial water treatment equipment” and domestic Ultraviolet cleanr industry standard for living and drinking water of CJ/T204-2000.
Internal & external polishing mirror chamber with high brightness for greatly improved UV intensity and clean effect.





Here are some solutions offered by Netech for the nautical sector:



▪ Removal of odors coming from the air vents of black water and gray water tanks;



▪ Purification and reclamation of freshwater in tanks;



▪ Elimination of odors due to stagnation in the bilges;



▪ Sanitation of UTA and Fancoils ducts as well as the air injected in the cabins;



▪ Environmental reclamation



Specification:


Model

Water flow

(T/Hr)

Power

(W)

Size

(mm)

Water Input & Ouput Size

Max Pressure

(Mpa)

NT-UV005G 0.1 8 250×48×65 1/4″ 0.8
NT-UV01G 0.2 10 295×60×80 1/4″
NT-UV02G 0.5 14 370×60×80 1/2″
NT-UV04G 1 17 450×73×110 1/2″
NT-UV06G 1.3 23 520×73×110 3/4″
NT-UV08G 1.8 28 650×73×110 3/4″
NT-UV12G 2.7 40 950×73×110 1″



Model

Water flow

(T/Hr)

Power

(W)

Size

(mm)

Water Input & Ouput Size

Max Pressure

(Mpa)

NT-UV3T 3 40×1 950×125×250 1″ 0.8
NT-UV5T 5 40×2 950×138×280 1.2″
NT-UV8T 8 40×3 950×170×310 1.5″
NT-UV12T 12 40×4 950×195×335 2″
NT-UV15T 15 40×5 950×195×335 2″
NT-UV20T 20 80×3 950×205×405 2.5″
NT-UV25T 25 80×4 950×275×465 2.5″
NT-UV30T 30 120×3 1250×275×545 3″
