60 grams Aquaculture Ozone Generator For Water cleanr And cleanion
Netech Ozone products Catalogue.pdf
Description
Gas source | Oxygen system inside | ||
Material | Enamel tube | ||
Cooling | Water cooling | ||
Power supply | 220V , 50HZ | ||
Commodity | Ozone water treatment system | ||
Ozone output | 40g 50g 60g 80g 100g 150g (customize) |
Features:
1. It has inside oxygen system, carbon steel sprayed with plastic or SS housing complete ozone generator
2. Use water cooling enamel ozone tube, high frequency electric board, thus max ozone concentration: 100Mg/L with stable ozone capacity, long life time
3. Adjustable ozone: 20%--100%,
4. Use with over current, over voltage, water protection device, for ensuring ozone machine running safety
Specifications:
Item | Unit | NT-Y40G | NT-Y50G | NT-Y60G | NT-Y100G |
Oxygen flow rate | LPM | 5~15 | 8~18 | 20 | 16-32 |
Ozone concentration | Mg/L | 90~56 | 90~60 | 55-59 | 90~58 |
Ozone output | G/Hr | 27~50 | 43~64 | 66-70.8 | 86~111 |
Power | Kw | ≤1.62 | ≤1.85 | ≤2.80 | 3.5 |
Fuse | A | 15 | 20 | 20 | 20 |
Cooling water flow | LPM | 48 | |||
Size | cm | 65*103*124 | 60*85*131 | 67*110*136 |
1. Above ozone capacity were tested under oxygen source
2. Net weight will be 10% different for different plug
Ozone Benefits for Wastewater Treatment:
-More effective than chlorine in destroying viruses and bacteria
-Utilizes a short contact time
-No harmful residuals that need to be removed after ozonation because ozone decomposes rapidly
-No regrowth of microorganisms, except for those protected by the particulates in the wastewater stream
-Generated onsite, and thus, there are fewer safety problems associated with shipping and handling
-Elevates the dissolved oxygen (DO) concentration of the effluent
-Can eliminate the need for reaeration and also raise the level of DO in the receiving stream
Clean, safe, and reliable, taking up less space, and less equipment than many chemical treatment/storage systems
-Saves money by eliminating on-going chemical costs
-Filtration will not be necessary after ozone cleanion
-Fewer secondary by-products like trihalomethones (THM) are formed with the use of ozone
-Ozone is most effective, however, by either eliminating or significantly reducing precursors in the raw water responsible for THM formation.
-Oxidation of odor causing compounds in the water may also be a secondary effect of ozone use in wastewater
-Odor control may be completed during the cleanion process
