1. Introduction “Sodium Hypochlorite Generator CK-50” , It has the advantages of convenient, safe , effective , mobility and on-site production. Besides, it is also very economical and affordable disinfect water production equipment. The product’s sodium hypochlorite disinfect water produced by the method of electrolytic salt water can not only disinfection and sterilization effect, but also disinfection of drinking water, non-toxic and harmless. It is very necessary in daily life. Compared with the “High Concentration Sodium Hypochlorite Disinfect water” produced by chemical factory, the “Sodium Hypochlorite Disinfect water” produced by this product is low in concentration, convenient to use, and has no harmful chlorine components to human body. 2. Material “Sodium Hypochlorite Generator CK-50” is a kind of intelligent generator for disinfect water solution. The power supply control system and titanium electrode coated with special materials are adopted. The electrolytic cell is made of PVC resin and titanium material. The electrolytic process is controlled automatically by setting time function. 3. Features Sodium hypochlorite, the main component of disinfect water, is a strong oxidant with strong bactericidal effect, which can replace “Bleaching Powder” and other oxidants.
Item No. | Output Voltage(V) | Output Voltage(V) | Operating Current (A) |
NaClO output
(g/h)
|
NaClO Concentration(ppm) |
Dimension
(cm)
|
CK-50 | DC12 | 280 | ≤ DC 20A | 50 | 3000~5000 |
Control box:34*18*29.5
Generator:12.5*20*53
|
CK-100 | DC24 | 600 | ≤ DC 25A | 100 | 5000~7000 |
Control box:34*18*29.5
Generator:12.5*20*53
|
Notice: 1) Input Voltage: AC110V, AC170 ~ 250V, 50 ~ 60Hz Output Voltage: DC12 or DC24C 2) The Best Operating Current: CK-50: DC15A~20A , CK-100: DC 20A~25A 3) Set Time Range: CK-50: 60minor 120min , CK-100: 60min or 90min 4) Automatic stop function after production. 5) Production conditions:Non iodized salt 500g, tap water 20L. 6) The depth of the water should submerge the disinfectant generator. 7) Working lifetime: ≥ 10 000 hours.
