Air Cooling Swimming Pool Ozone Generator 10g 15g 20g

Air Cooling Swimming Pool Ozone Generator 10g 15g 20g

  • High Light

    Air Cooling Swimming Pool Ozone Generator

    ,

    20g Swimming Pool Ozone Generator

    ,

    10g Water Ozone Generator

  • Timer
    One Or Two Recycle Working Time
  • Ozone Capacity
    2g 3g 5g 6g 10g 15g 20g
  • Cooling Way
    Air Cooling
  • Gas Feed
    Ambient Air Or Outside Oxygen Source
  • Warranty
    One Year
  • MOQ
    1 Set
  • Place of Origin
    China
  • Brand Name
    ozocenter
  • Model Number
    CH-T
  • Minimum Order Quantity
    1 set
  • Price
    USD 300 - USD 900
  • Packaging Details
    with froth in cartons or wooden case
  • Delivery Time
    3 to 5 working days
  • Payment Terms
    paypal,western union,T/T,credit card, L/C
  • Supply Ability
    1000 per weeks

Air Cooling Swimming Pool Ozone Generator 10g 15g 20g

Swimming Pool Ozone Generator Water Treatment Ozonated Sterilization and Disinfection




Quick details



    Brand Name:                    Netech

Model Number:                NT-T-N

Certification:                    domestic
Ozone output way:          air cooling

Warranty:                        one year warranty


Description



Gas source Oxygen
Oxygen flow rate 0.5LPM-10LPM
Material Ceramic tube
Cooling Air cooling
Power supply 220V,50/110V,60HZ
Commodity Ozone water system
Ozone output 2g/3g/5g/6g/10g/15g/20g
Size 360*260*610/400*300/770mm



How to use ?



1. Before use this machine, put it in a stable flat place which can hold its weight.

2. Use the power equipped with the machine;

3. The machine use for air purification, firstly attach the silicone tube into the

ozone outlet and then turn on the power;

4. Set the timer and then come out ozone, and put the tube into the room.

5. When use for room air purification, it requires nobody is present, after 30

minutes people can walk into the room.

6. If use for water treatment, the air stone should be attached into the silicone

tube and put into the water.

7. Attention,the machine should be placed higher than the water, incase that the water reflux occur.




Control panel:



Voltmeter, Ammeter, Switch, Timer, Working light, Power light etc.


Timer: One or Two recycle working time



Applications:



1. treatment industry: clean sick room, operating room, treatment equipment, aseptic room, etc
2. Fruits and vegetables: keep fruits and vegetables fresh and store them
3. Sea food factory: Remove smell of sea food factory and kill bacteria, clean production water supply.
4. Slaughtering: Remove smell of slaughtering and kill bacteria, clean production water supply.
5. Poultry factory: Remove smell of poultry factory and kill bacteria,clean water for poultry feeding.
6. Commercial use in House, hotel, Office, KTV, Super Market, Fruit shop etc.
Air Purifier: Remove formaldehyde, benzene compounds, Smoke, Odors, Molds, Virus to fresh air.
Water purifier: clean production Water supply.
7. Bottle Water, Domestic Water, Well Water, Pool Water cleanion & clean



Features:



1. Built in Domestic ed Product -Air cooling ceramic ozone generator
2. Built in Automatic air dryer, Feed dry air or outside oxygen source
3. Connect with external ozone injector for water treatment
4. It can be Movable with wheels & Handles or Wall mounted.
5. No breakdown with easy operation and maintenance.



NT-T-N Specifications:



Item Unit NT-T-N
2G 3G 5G 6G 10G 15G 20G
Oxygen flow rate LPM 0.5~2 1~3 1.2~3 1.5~3.5 2.4~6 3.6~9 3~10
Ozone concentration Mg/L 28~50 28~65 32~60 28~56 32~60 32~60 38.9~42
Ozone output G/Hr 1.5~3.0 4~5.0 4.3~5.7 5.0~5.8 8.6~14.5 13~17 18.6~20
Power W 115 135 160 185 260 330 400
Air flow rate (Suggested) LPM 40~60 50~75 50~90
Compressed air pressure Mpa 0.025
Fuse of power supply A 3 5 5 5
Size cm 36×26×61 40×30×77
Net Weight kg 11.25 11.30 11.50 18 20 35


Noted:

1. Above ozone capacity were tested under oxygen source

2. Net weight will be 10% different for different plug.



Quality control



Every procedure has personnel inspection.

All the products must be tested and qualified before packaging.





We are professional in manufacturing different ozone generators, oxygen generators and related spare parts for 10 years.

The products are widely used in air purify, water treatment, aquaculture, food processing, etc.
