Ceramic tube swimming pool ozone generator ozonator 10g for industrial polluted water

Ceramic tube swimming pool ozone generator ozonator 10g for industrial polluted water

  • High Light

    ozone generator swimming pool

    ,

    ozone generator water treatment swimming pools

  • Place of Origin
    China
  • Brand Name
    Netech
  • Model Number
    NT-YFC
  • Minimum Order Quantity
    1
  • Price
    300-900USD
  • Packaging Details
    with froth in cartons or wooden case
  • Delivery Time
    3 to 5 days
  • Payment Terms
    paypal,western union,T/T,credit card
  • Supply Ability
    1000 per weeks

Ceramic tube swimming pool ozone generator ozonator 10g for industrial polluted water

Ceramic tube swimming pool ozone generator ozonator 10g for industrial polluted water







Quick details

Brand Name:              Netech

Model Number:           NT-YFC

Certification:               domestic
Ozone output way:      air cooling

Warranty:                    one year warranty
Adjustable rate:           20-100% adjustable ozone

Description

MOQ: 1 set

Gas source Oxygen
Oxygen flow rate 1-18LPM
Material Ceramic tube
Cooling Air cooling
Power supply 220V,50/60HZ
Commodity Ozone water system
Ozone output 5g/10g/15g/20g/30g

how to use ?

1. Before use this machine, put it in a stable flat place which can hold its weight.

2. Use the power equipped with the machine;

3. The machine use for air purification, firstly attach the silicone tube into the

ozone outlet and then turn on the power;

4. Set the timer and then come out ozone, and put the tube into the room.

5. When use for room air purification, it requires nobody is present , after 30

minutes people can walk into the room.

6. If use for water treatment, the air stone should be attached into the silicone

tube and put into the water.

 7. Attention, the machine should be placed higher than the water, incase that the water reflux occur.



Features:

1. Carbon steel sprayed with plastic housing;

2. Built-in PSA high purity twelve tower oxygen sieve;

3. Built-in of product –Air cooling Ceramic ozone tube with high frequency electric board, high ozone concentration and stable ozone capacity, long life time;

4. Built-in Oil-free air compressor;

5. Built-in Air dryer and filters. To supply cool, dry, clean air source for air compressor and PSA oxygen concentrator;

6. Manual control, easy operation and maintenance.



Control panel:

Voltmeter, Ammeter, Timer, Ozone Ammeter, Main switch, Power supply switch, Emergency stop, working light, Power light, Alarm



Control protection:

Over current protection

Electric leakage protection

Short circuit protection

Over heat of air compressor protection

Time delay system protection



Application

1. treatment industry: clean ward, operating room, treatment equipment, aseptic room, etc;

2. Laboratory: industrial oxidation of flavor and pharmaceutical intermediate;

3. Food processing industry: keep fruits and vegetables fresh and cold storage; rice & wheat storage; or storage room air clean.

4. Sea food factory: Remove smell of sea food factory and kill bacteria;

5. Slaughtering: Remove smell of slaughtering and kill bacteria;

6. Poultry factory: Remove smell of poultry factory and kill bacteria;

7. Green house: air clean and kill bacteria.

8. Agricultural: fish farm water treatment

9. Swimming pool water treatment

10. Drinking water treatment

Specifications

Item Unit NT-YFC5G NT-YFC10G NT-YFC15G NT-YFC20G NT-YFC30G
Oxygen flow rate LPM 3 3.5 5 8 10
Ozone concentration Mg/L 48.5~52.3 48.5~52.3 49.5~51.2 38.9~41.7 53.2~56.1
Ozone output G/Hr 5 10~11 14.8~15.4 18.6~20 32~34
Power KW ≤0.48 ≤0.81 ≤0.924 ≤1.00 ≤1.23
Current A 2.2 3.6 4.2 4.5~4.7 5.6±5%
Voltage V 220V/50HZ
NW KG 64 86 89 92 97
Size cm 45x50x84 50×66×95 45*93*118




Noted:

1. Above ozone capacity were tested under oxygen source

2. Net weight will be 10% different for different plug










Quality control



Every procedure has personnel inspection.

All the products must be tested and qualified before packaging.



After sales service



We provide 12 month free maintenance.

The buyer should return the product in the original conditions to us and should

bear the shipping costs for return.


Question and answer
Is ozone harmful to human body ?
Once the ozone concentration fails to meet the hygiene and safety standard,
we can notice with our sense of smell and dodge away or take actions to avoid
further leakage.
So far there is no one death reported caused by ozone poisoning.


Does the ozone generator work efficently ?
Undeniably, ozone can clean and remove odor and formaldehyde.
It is reported that ozone is a widely used bactericide. It can kill escherichia coli,
bacteria efficently and resolve the harmful material in a short time.
