Oxygen Concentrator Aquaculture Ozone Generator

Oxygen Concentrator Aquaculture Ozone Generator

  • High Light

    ozone generator for fish farm

    ,

    ozone generator water purifier

  • Material
    Carbon Steel
  • Ozone Output
    10-200g/h
  • Warranty
    1 Year
  • Voltage
    110V/220V
  • Application
    Swiming Pool, Seawater Aquaculture, Car, Fish Farming/Medical/industrial/medical, Water Sterilization;Air Purification
  • Kayword
    Ozone Generator For Water Treatment
  • Place of Origin
    China
  • Brand Name
    Osunshine
  • Model Number
    CH-Y
  • Minimum Order Quantity
    1 set
  • Price
    For further discussion
  • Packaging Details
    with foam in cartons or wooden case
  • Delivery Time
    3 to 5 working days
  • Payment Terms
    paypal, western union, T/T, credit card, D/P
  • Supply Ability
    500 per weeks

Oxygen Concentrator Aquaculture Ozone Generator

Built-in Oxygen Concentrator Aquaculture Ozone Generator
Oxygen Concentrator Aquaculture Ozone Generator 0

Quick Details



Brand NameOsunshine
Model NumberCH-Y
CertificationDomestic
Ozone output wayCorona Discharge
WarrantyOne Year Warranty
Adjustable rate20-100% Adjustable Ozone



Description

MOQ: 1 set

Gas sourceOxygen
Oxygen flow rate1-18LPM
MaterialEnamel tube
CoolingWater cooling
Power supply220V,50/60HZ
CommodityOzone water system
Ozone output10g/20g/30g/40g/50g
Size500*830*1110/650*170*175mm



How to use?



1. Before use this machine, put it in a stable flat place which can hold its weight.

2. Use the power equipped with the machine;

3. The machine use for air purification, firstly attach the silicone tube into the

ozone outlet and then turn on the power;

4. Set the timer and then come out ozone, and put the tube into the room.

5. When use for room air purification, it requires nobody is present , after 30

minutes people can walk into the room.

6. If use for water treatment, the air stone should be attached into the silicone

tube and put into the water.

7. Attention, the machine should be placed higher than the water, incase that the water reflux occur.


Features:



1. With built-in oxygen system, carbon steel sprayed with plastic or SS housing complete ozone generator

2. With built-in water cooling enamel ozone tube, high frequency electric board, thus max ozone concentration: 100Mg/L with stable ozone capacity, long life time
3. Adjustable ozone range: 20%--100%, it can working automatic
4. Compact assembly,Movable with Wheels

5. Use with over current, over voltage, water protection device, for ensuring ozone machine running safety


Control panel:


Ozone output adjuster, Voltmeter, Ampmeter, Timer, Cooling water temperature indicator, Ozone Ampmeter, Main switch, Power supply switch, Emergency stop, Working light, Power light, Alarm




Specifications



ItemUnitCH-Y40GCH-Y50GCH-Y100G
Oxygen flow rateLPM5~158~1816-32
Ozone concentrationMg/L90~5690~6090~58
Ozone outputG/Hr27~5043~6486~111
PowerKw≤1.62≤1.853.5
FuseA152020
Cooling water flowLPM48
Sizemm650×1030×1230650×1030×1230


Noted:
1. Above ozone capacity were tested under oxygen source
2. Net weight will be 10% different for different plug


Question and answer

♦ Is ozone harmful to human body ?
Once the ozone concentration fails to meet the hygiene and safety standard,
we can notice with our sense of smell and dodge away or take actions to avoid
further leakage.
So far there is no one dead reported caused by ozone poisoning.
♦ Does the ozone generator work efficiently ?
Undeniably, ozone can clean and remove odor and formaldehyde.
It is reported that ozone is a widely used bactericide. It can kill escherichia coli,
bacimethrin efficiently and resolve the harmful material in a short time

Oxygen Concentrator Aquaculture Ozone Generator 1
Oxygen Concentrator Aquaculture Ozone Generator 2
Oxygen Concentrator Aquaculture Ozone Generator 3

QUALITY CONTROL

In order to ensure the best quality, every ozone generator has been strictly tested
before delivery.
We promise the good performance and all parts completely
according to your


ABOUT US

Gold supplier--Guangzhou Netech Environmental Technology Co., Ltd ,15 years of experience in Water Treatment and Environment R&D and Engineering,
we are able to solve all your solutions in Environmental Protection and Water Treatment.
High quality guarantee
Good after-sale service


QUALITY CONTROL

Every procedure has personnel inspection. All the products must be tested and qualified before packaging.


Place of Origin:China
Brand Name:Osunshine
Model Number:

CH-Y



EXW price$5000 - 8100
Packaging Details:Carton case / sea wooden case
Delivery Time:5 -10 days
Payment wayT/T / Western union / credit card / D/A / D/P / L/C paypal
Payment Terms:EXW/FOB/CIF
Supply Ability:1500sets/month



AFTER SERVICE


We provide 12month free maintenance.

The buyer should returnthe product in the original conditions

to us and should bear
the shipping costs for return.
If any part is required to be replaced,the buyer should also pay for th costs of the parts to be replaced.


PROMPT DELIVERY

1.3-7 days for portable ozone generator/ozone generator spare parts order;
2.10-30 days for industrial/middle size ozone generator order;
3.Shipping could be courier, airline or sea
Package


A) Inner layer: plastic bag
B) Middle layer: EPE(Expand aple poly ephylene)
C) Outer Layer: carton/composite wooden



We are the trusty partner! Buy base on the trust !
