90% Oxygen Concentrator Parts O2 For Ozone Equipment

90% Oxygen Concentrator Parts O2 For Ozone Equipment

Products - Oxygen Concentrator Parts
  • High Light

    Two towers oxygen concentrator

    ,

    90% Oxygen Concentrator Parts O2

    ,

    60Hz Two towers oxygen concentrator

  • Product Name
    Two Towers Oxygen Concentrator
  • Oxygen Output
    3L,5L,8L, 10L
  • Oxygen Purity
    90%±3%
  • Working Voltage
    AC110V/60Hz Or 220V/50Hz
  • Dimension
    460*260*510 Mm
  • Net Weight
    28 Kg
  • Oxygen Pressure
    ≥40KPa
  • Place of Origin
    China
  • Brand Name
    CHUANG
  • Certification
    ISO9001
  • Model Number
    HY-GOX8L
  • Minimum Order Quantity
    1
  • Price
    USD450-USD499
  • Packaging Details
    Wooden Case, Carton
  • Delivery Time
    5-15working days
  • Payment Terms
    L/C, T/T, Western Union, MoneyGram, Paypal
  • Supply Ability
    100 SETS 15DAYS

90% Oxygen Concentrator Parts O2 For Ozone Equipment

  • 90% Oxygen Concentrator Parts O2 For Ozone Equipment
  • 90% Oxygen Concentrator Parts O2 For Ozone Equipment
  • 90% Oxygen Concentrator Parts O2 For Ozone Equipment
  • 90% Oxygen Concentrator Parts O2 For Ozone Equipment
  • 90% Oxygen Concentrator Parts O2 For Ozone Equipment
  • 90% Oxygen Concentrator Parts O2 For Ozone Equipment
Get Price Contact Now

90% oxygen concentrator parts O2 for oxygen machine ozone equipment

90% Oxygen Concentrator Parts O2 For Ozone Equipment 0

90% Oxygen Concentrator Parts O2 For Ozone Equipment 1



10LPM 90% oxygen concentrator parts O2 for oxygen machine ozone equipment



Introduction:

* The model of HY-GOX ( Integrated 2 tower oxygen molecular sieve concentrator) is specially used for equipment to supply oxygen source.

* It is prepared by the principle of high-efficiency molecular sieve PSA.

* It uses air as raw material, molecular sieve as adsorbent, and uses the principle of pressure swing adsorption to separate oxygen and nitrogen in the air. .

* Stable and reliable work, low working noise,

* It can be used independently or built into the ozone equipment system.



Features:

* Adopting double-row condensing radiator and powerful cooling fan, so that the high-temperature gas from the compressor can quickly form condensate droplets and be discharged.



* The multi-stage automatic water filtering function of the water filter and the dryer can fully filter the water in the compressed gas and greatly extend the service life of the molecular sieve.

* Powerful heat dissipation at the bottom and condensation technology at the top of the air compressor ensure that the air compressor can run for a long time without getting hot.

* Adopt high-efficiency molecular sieve material, which is stable and durable in operation.

* This parts is manufactured according to the standard of medical oxygen generator, with high oxygen concentration, low machine vibration and low noise.



Specification

Product name Integrated 2 tower oxygen molecular sieve concentrator
Model no. HY-GOX3L HY-GOX5L HY-GOX8L HY-GOX10L
Oxygen output 3L/min 5L/min 8L/min 10L/min
Oxygen concentration ≥90%±3%
Input voltage AC220V/50Hz
Power ≤380W ≤520W ≤780W ≤800W
Oxygen output pressure ≥40KPa
Working noise ≤48dB(A)
Ambient temperature 5-45℃
Environment humidity ≤80%RH
Dimension 379*240*397mm 430*258*461mm 460*260*510 mm 460*260*586 mm
Net weight 16.5kg 22kg 28kg 30kg


Notice:

In order to prevent the compressor from swinging during transportation, we fixed the compressor with cable ties at the four corners.

Before using it for the first time, please cut off the 4 cable ties at the bottom and pull it out, and then you do not need to open the case during this process.



90% oxygen concentrator parts O2 for oxygen machine ozone equipment

90% Oxygen Concentrator Parts O2 For Ozone Equipment 2



90% oxygen concentrator parts O2 for oxygen machine ozone equipment

90% Oxygen Concentrator Parts O2 For Ozone Equipment 3

90% Oxygen Concentrator Parts O2 For Ozone Equipment 4



90% oxygen concentrator parts O2 for oxygen machine ozone equipment

Company Introdcution:

Guangzhou OSUNSHINE Environmental Technology Co., Ltd., based on the parent company of Guangzhou Chuanghuan Ozone Electric Appliance Co., Ltd. which was established in 2006, It focuses on Ozone generator, Oxygen machine, Sodidum Hypochlorite generator, Ozone tube, Titanium anode plate, accessories production, development and application of products etc.

With the development for several years, the company has been in 16 aspects of the ozone generator. Most products have had CE certification.
We are the key suppliers for components of ozone generators in domestic and foreign manufacturers. Our products include the 100mg-10kg / h of ozone and ozone accessories.
