UV cleanr Ozone Generator Water Purification for Farm Pond Pool Fountain

Place of Origin Guangdong China
Brand Name Netech
Model Number NT-UV40T-500T
Minimum Order Quantity 1 set
Price For futher discussion
Packaging Details Safe double carton package with foam inside for protection
Delivery Time 3-8 days after payment confirmed
Product Details
Max Pressure 0.8 Mpa Function Clean And Cleanion
Application Water Purification Farm Pond Pool Fountain Material Swimming Pool, Drinking Water, Aquaculture
Water Flow Rate 40T-500T / Hr
High Light

water treatment ozone generator

,

ozone generator water treatment

Leave a Message
Product Description

40-500T UV cleanr Ozone Generator Water Purification Farm Pond Pool Fountain





Features:


Water flow rate: 0.1-500 ton/hr which can meet with different water capacities.

Warranty: 10 years warranty for stainless steel housing, other components are 1 year.

Material: Use SS304 or SS316L material for reaction chamber, combined with full-automatic welding. All connections are smoothly without any corner;

The whole system adopts America NSF55 standard of “Ultraviolet microbial water treatment equipment” and domestic Ultraviolet cleanr industry standard for living and drinking water of CJ/T204-2000.

Use America Hanovia lamp tube.



Parts:


Chamber: Internal & external polishing mirror chamber with high brightness for greatly improved UV intensity and clean effect.

Thickness: The thickening design of chamber which is strictly tested air & water pressure before shipping. It can withstand 0.8 Mpa, and fully prevents from water leakage.

Lamp: Use imported low-pressure but high-strength mercury lamp, which has 9000-13000 hrs service life(Max); assorted with high-efficiency electron ballast, it improves product service life and effect, so that the sterilizing rate up to 99.99%.



Parameter table



Model

Water flow

(T/Hr)

Power

(W)

Size

(mm)

Water Input & Ouput Size

Max Pressure

(Mpa)

NT-UV40T 40 120×4 1250×275×550 3″ 0.8
NT-UV50T 50 120×5 1250×275×550 4″
NT-UV60T 60 150×5 1650×280×495 4″
NT-UV70T 70 150×6 1650×305×520 5″
NT-UV80T 80 150×7 1650×305×520 5″
NT-UV100T 100 150×8 1650×335×550 6″
NT-UV125T 125 150×10 1650×360×575 6″
NT-UV150T 150 150×12 1650×385×600 8″
NT-UV200T 200 150×16 1650×460×675 8″
NT-UV500T 500 240×25 1650×650×750 DN300
