Water Ozone Treatment Aquaculture Ozone Generator for Aquaculture RAS System

Water Ozone Treatment Aquaculture Ozone Generator for Aquaculture RAS System

  • High Light

    spa necessities ozone generator

    ,

    ozone generator water purifier

  • Cooled Method
    Air Cooled
  • Ozone Produced Way
    Corona Discharge
  • Ozone Output
    3g 5g 6g 7g
  • Timer
    0-30 Mins Or Continuously
  • Working Voltage
    20%-100%
  • Warranty Period
    12 Months
  • Place of Origin
    China
  • Brand Name
    ozocenter
  • Model Number
    CH-BP
  • Minimum Order Quantity
    1 set
  • Price
    For further discussion
  • Packaging Details
    with froth in cartons or wooden case
  • Delivery Time
    2 to 3 working days
  • Payment Terms
    paypal,western union,T/T,, L/C
  • Supply Ability
    3000 per weeks

Water Ozone Treatment Aquaculture Ozone Generator for Aquaculture RAS System

Healthmate Air Purifier And Water Ozone Treatment In Aquaculture RAS System





Quick Detail



1. Adjustable ozone :20%-100%

2. high concentration

3. Corona Discharge technology

4. usage: water, air,vegetables and fruits washing,etc

5. Ozone output:3G/Hr, 5G/Hr, 6G/Hr, 7G/Hr

6. Application:ozone food cleanr,air,water, room,hotel,office





Features:

  1. Corona Discharge technology
  2. Built in Domestic -Ceramic ozone tube with electric board
  3. Adjustable ozone output: 20%-100%
  4. Two function for timer: 0-30 mins or working continuously
  5. Ozone output:3g/h, 5g/h, 6g/h, 7g/h
  6. Changeable plug for different counties.



Configurations:

1. Mini air pump.

2. Air cooled ceramic ozone tube.

3. Power supply.

4. Fans for cooling.





How to use ?



1. Before use this machine,put it in a stable flat place which can hold its weight.

2. Use the power equipped with the machine;

3. The machine use for air purification,firstly attach the silicone tube into the

ozone outlet and then turn on the power;

4. Set the timer and then come out ozone, and put the tube into the room.

5. When use for room air purification, it requires nobody is present , after 30 minutes people can walk into the room.

6. If use for water treatment, the air stone should be attached into the silicone tube and put into the water.

7. Attention,the machine should be placed higher than the water, incase that the water reflux occur



(NOTE: The model CH-BP can use the outside oxygen source)





Functions:



clean: Can quickly kill all bacteria, viruses, but without secondary pollution.

Detoxication: effective remove of pesticide residues from food.

Remove odor: musty, smoke, smoke flavor, water stains etc.
Improve oxygen: improve oxygen for water or air.
Healthy: air purify, expedite human metabolism.

New Improvement of CH-BP 2-6g/hr ozone generator:

Air source with inside air pump, also can connect outside oxygen source.

It can meet with different requirements of ozone output & concentration for different application





Specification



Item Gas flow rate Ozone output Power Output gas tube Fuse Size NW
Model LPM G/Hr W mm A mm Kg
CH-BP3G 10 3 70 φ6 3 355×215×310 8.5
CH-BP5G 5 80 8.6
CH-BP6G 15 6 100 8.7
CH-BP7G 17 7 110 8.8





Noted:

1. Above ozone capacity were tested under oxygen source

2. Net weight will be 10% different for different plug.



V

V Various Applications:



1. Air purification, removing odors, smoke, mold, etc.

2. Water clean for home, commercial, industrial used.

3. ozone for drinking water treatment and bottling clean.

4. ozone for aquaculture water purification.

5. ozone for removing iron and manganese.

6. ozone for food storage, keep fruit, vegetable, products longer shelf life.

7. ozone for laundry system.

8. ozone for industrial polution control, removing odors, harmful gas.

9. ozone for food processing, factory, workshop clean.





Features:



· Domestic , CE certification
· Ozone adjustable range: 20%-100%
· Two function for timer: 0-30 mins or working continuously

· Assembled with air pump switch, it can connected with outside oxygen feed





QUALITY CONTROL



In order to ensure the best quality, every ozone generator has been strictly tested before delivery.

We promise the good performance and all parts completely

according to you





Why choosing us?



1.Having 10 years production experienced .We are trusty business partner.

2.Quality Controlled:Quality Control personnel check the quality at every stage

of production, from the incoming raw materials to the finished product.

3.NT-BP Production Capacity: 3000 pcs per month.

4.We have serial products: ozone tube ,UV water cleanrs, ozonegenerators, oxygen concentrators, protein skimmers, and filters, mixing pumps and other water or air treatment spare parts.

5.We supply OEM service according to customers' requests and give out professional suggestions.



Distributors Offer : Welcome to be our distributor .
