Twelve Towers Zeolite Molecular Sieve Oxygen Generator Longer Lifespan For Home

Twelve Towers Zeolite Molecular Sieve Oxygen Generator Longer Lifespan For Home

  • High Light

    oxygen concentrator repair

    ,

    oxygen molecular sieve

  • Warranty
    1 Year
  • Noise
    ≤ 60Db
  • Application
    Oxygen Increasing
  • Output
    3L 5L 7L 10L 15L
  • Outlet Pressure
    0.06~0.08Mpa
  • Oxygen Purity
    93% + - 3%
  • Place of Origin
    China Guangzhou
  • Brand Name
    Netech
  • Model Number
    NTOX3-15AL
  • Minimum Order Quantity
    1
  • Packaging Details
    with froth in cartons or wooden case
  • Delivery Time
    3 to 5 days
  • Payment Terms
    paypal,western union,T/T,credit card
  • Supply Ability
    1000 per weeks

Twelve Towers Zeolite Molecular Sieve Oxygen Generator Longer Lifespan For Home

Twelve Towers Zeolite Molecular Sieve Oxygen Generator Longer Lifespan For Home





ed products



NT-OT series molecular sieve is an air separation plant which has already obtained domestic .





Rational construction



Modular construction is the main points of our molecular sieve. Through the different combination of oxygen units, the oxygen output can be from 1 LPM to 160 LPM, even higher.





Easy to control



Each unit can be work independently, according to the different oxygen output requirement. And free control for the different unit combinations. So that, it can be suitable used for the standardization of products. Meanwhile, maintenance will be more convenient.





The oxygen output is stable and continuously





Low-pressure oxygenproduction working pressure less than 3 KG.



Zeolite material Specifications



Item Unit NTOX3ZE-1 NTOX5ZE-1 NTOX7ZE-1 NTOX10ZE-1
Oxygen output LPM 3 5 7.5 10
Oxygen concentration % 90%±5%
Air flow rate LPM 36-45 60-75 90-115 150-200
Pressure(inlet) Mpa 0.14-0.18 0.14-0.18 0.15-0.2 0.18-0.25
Pressure(outlet) Mpa 0.06-0.08
Temperature °C indoor temperature
Relative humidity % ≤ 70%±10%
Noise Db ≤60 ≤60 ≤60 ≤60
Dimension mm 200×290 200×410 200×470 200×500
Net weight kg 5.25 6.85 7.8 10



Aluminum Material Specifications



Item Unit NTOX3AL-2 NTOX5AL-2 NTOX7AL-2 NTOX10AL-2
Oxygen output LPM 3 5 7.5 10
Oxygen concentration % 90%±3% 90%±3% 90%±3% 90%±3%
Air flow rate LPM 36-45 60-75 90-115 150-200
Pressure(inlet) Mpa 0.14-0.18 0.14-0.2 0.15-0.21 0.18-0.25
Pressure(outlet) Mpa 0.06-0.08 0.06-0.08 0.06-0.08 0.06-0.08
Temperature °C indoor temperature
Relative humidity % ≤ 70%±10%
Noise Db ≤60 ≤60 ≤60 ≤60
Dimension mm 200×310 200×430 200×500 200×560
Net weight kg 5.5 7.0 8

11
