1mg/l 4mg/h Ozone Generator Water Purification Ozonator Water Making Machine
|Power supply||220V , 50 / 60HZ|
|Commodity||Ozone water system|
|Rated Water flow||1800~2400 Liter per hour|
NT-WCZ-2, this system can produce OZONE WATER 1800~2400 liter per hour, and it can controls output of ozone dissolved water with concentration from 4mg/l to 15mg/l.
1. Stainless steel housing
2. Built-in Air dryer and PSA high purity oxygen concentrator
3. Built-in of product –ozone generator tube with high frequency electric board
4. Built-in High efficiency ozone mixing system
5. It can be Movable with wheels
6. Built in anti water return equipment, it can prevent water return back to machine.
7. All the pipe and pipe fittings is stainless steel material
8. It can custom-made according to customer’s requirement.
9. Easy operation.
Ammeter, Voltmeter, Timer, Emergency stop, working light, Power light, Trouble Alarm, Working light, Start light, Stop light
The use of ozone for surface sanitation is one of the best processes we have to offer. Not only can ozone be used to sanitize the surfaces of your facility and equipment, but it can also be used to clean the surfaces of your products, produces, and meats. You can properly sanitize your surfaces with both gas and aqueous ozone. It is most effect, when using just gas, to shock treat your facility. This will not remove all contaminants, but will drastically reduce them. We also provide ozone injection systems that dissolve ozone into water for you to utilize and spray on any surfaces needing to be cleaned. NETECH' products are heavily used for this purpose throughout the world and can be easily incorporated into your current processes.
Ozone Benefits for Surface Sanitation
- Ozone has no residuals or by-products that could alter flavors of a beverage or other product.
- Ozone sanitation may replace hot water cycles, lowering energy costs.
- Chemicals like chlorine or other sanitizers can be eliminated, saving cost and labor in handling/transporting chemicals.
- Rinse/cleaning cycles can be combined using ozone; saving water and time. This may allow for more processing time, due to a shorter cycle time.
|High pure ceramic ozone tube||Long use life, high ozone concentration, low temperature, continuous working|
|High frequency and high pressure ozone power board||Adjustable frequency, adjustable width and audible alarm. It will not damage the power board if circuit break or short circuit.|
|Oil free air compressor||Offer clean air source|
|Air dryer||Offer clean and dry air source|
|PSA high pure oxygen sieve||Offer oxygen purity: 93%|
|Stainless steel high efficiency gas liquid mixing pump||The pump sucks the liquid and air, then mix them. The micro air bubble of gas-liquid dissolving effect is good|
|Stainless steel high efficiency static mixer||Enhance dissolved effect is more than three times|
|Stainless steel anti water return equipment||It can prevent water return back to machine|
|Water level sensor||Prevent the equipment running without water or lack of water|
|Alarm device||Humanized remind users equipment anomalies|
|NT - WCZ - 2|
|Working Voltage||V/HZ||220V / 50HZ / 60HZ|
|Dissolved ozone concentration in water||PPM||4-15|
|Rated Water flow||L/hr||1800~2400 Liter per hour|
|Ambient temperature||℃||3 - 40℃|
|Ambient Humidity||%||≤ 70%|
|Water Output Pressure||Mpa||0.05-0.2Mpa|
|Diameter of input water pipe||inch||1"|
|Diameter of output water pipe||inch||3 4"|
Noted: Net weight will be 10% different for different plug
It can be customize made according to customers requirements.
