Air Or Oxygen Source Ozone Generator Water clean For Agriculture 2g 30g
Descriptions:
| Gas source | Oxygen |
| Oxygen flow rate | 1-18LPM |
| Material | Ceramic tube |
| Cooling | Air cooling |
| Power supply | 220V,50/60HZ |
| Commodity | Ozone water system |
| Ozone output | 2g/3g/5g/6g/10g/15g/20g/30g |
| Size | 360*260*610/400*300/770mm |
Control panel:
Voltmeter, Ampmeter, Switch, Timer, Working light, Power light etc.
Timer: One or Two recycle working time
Applications:
1. treatment industry: clean ward operating room, treatment equipment, aseptic room, etc
2. Fruits and vegetables: keep fruits and vegetables fresh and store them
3. Sea food factory: Remove smell of sea food factory and kill bacterias , clean production water supply.
4. Slaughtering: Remove smell of slaughtering and kill bacteria, clean production water supply.
5. Poultry factory: Remove smell of poultry factory and kill bacteria ,clean water for poultry feeding.
6. Commercial use in House, hotel, Office, KTV, Super Market, Fruit shop etc.
Air Purifier: Remove formaldehyde, benzene compounds, Smoke, Odors, Molds, Virus to fresh air.
Water purifier: clean production Water supply.
7. Bottle Water, Domestic Water, Well Water, Pool Water cleanion & clean
Features:
1) ISO certificate for 2g/hr,3g/hr,.....30g/hr,or even higher capacity 40g/hr,50g/hr,60g/hr
2) Movable design for air purifier or water treatment
3) Installed with domestic air cooled ceramic ozone generator tube
4) Stable ozone output performance, don't support with adjustable ozone output
5) Ozone generator is air cooled type unit, cooling fan will take away the heat which released by
ceramic ozone tubes and electric cards.
6) This equipment uses air as feed gas with built-in oil free air compressor or connects with
outside oxygen source. This type is easier and safer to be operated.
Specifications:
| Item | Unit | NT-T-N | |||||||
| 2G | 3G | 5G | 6G | 10G | 15G | 20G | 30G | ||
| Oxygen flow rate | LPM | 0.5~2 | 1~3 | 1.2~3 | 1.5~3.5 | 2.4~6 | 3.6~9 | 3~10 | 3-10 |
| Ozone concentration | Mg/L | 28~50 | 28~65 | 32~60 | 28~56 | 32~60 | 32~60 | 38.9~42 | 51~70 |
| Ozone output | G/Hr | 1.5~3.0 | 4~5.0 | 4.3~5.7 | 5.0~5.8 | 8.6~14.5 | 13~17 | 18.6~20 | 12.6~30.6 |
| Power | W | 115 | 135 | 160 | 185 | 260 | 330 | 400 | 1100 |
| Air flow rate (Suggested) | LPM | 40~60 | 50~75 | 50~90 | 36 | ||||
| Compressed air pressure | Mpa | 0.025 | 0.14 | ||||||
| Fuse of power supply | A | 3 | 5 | 5 | 5 | 10 | |||
| Size | cm | 36×26×61 | 40×30×77 | 40*28*101 | |||||
| Net Weight | kg | 11.25 | 11.30 | 11.50 | 18 | 20 | 35 | 33.5 | |
Noted:1. Above ozone capacity were tested under oxygen source
2. Net weight will be 10% different for different plug.
Tips
1. If use it for air purify, please close door and windows, you just set working time and you can walk away after you coming back will get fresh air.
2. If use it for water purify, please put ozone mchine higher than water for preventing water into machine or you can use with check valve.
3. All kinds of plug are availbale, 110V 220V are available, when you make order pls kindly note us the voltage and plug, thanks a lot!
