40G 50G Water Cooled Food Ozone Generator For Cold Storage cleanion
Quick Details:
| Adjustable range | 20%-100% |
| Cooling way | Air Cooling |
| Ozone output | 10g 20g 30g 40g 50 g/hr |
| Core parts | water cooling enamel ozone tube |
| Commodity | Ozone Water cleanr |
| Size | 460*390*840mm |
| Timer | 0-30 mins or working continuously |
| Functions | clean, Detoxication, Remove Odor... |
Features:
1. SS housing / carbon steel sprayed with plastic housing
2. It must connect with outside oxygen generator or oxygen tank
3. With built-in water cooling enamel ozone tube, high frequency electric board, thus max ozone concentration: 100Mg/L with stable ozone capacity, long life time
4. Small in size, adjustable ozone range: 20%--100%
5. Use with over current, over voltage, water protection device, for ensuring ozone machine running safety
Specifications:
| Item | Unit | NT-WZQ | |||||
| 10G | 20G | 30G | 40G | 50G | 60G | ||
| Oxygen flow rate | LPM | 1~3 | 2~7 | 3~10 | 5~10 | 8~18 | 8~20 |
| Ozone concentration | Mg/L | 69~88 | 52~104 | 56~93 | 85~116 | 60~90 | 60-70 |
| Ozone output | G/Hr | 5~12 | 12~22 | 16~33 | 34~51 | 43~64 | 72-84 |
| Power | W | 220 | 250 | 400 | 510 | 600W | 840W |
| Fuse | A | 3 | 3 | 3 | 5 | 6 | 6 |
| Cooling water flow rate | LPM | 30 | 48 | 48 | |||
| Size | mm | 460×390×840 | |||||
