12V 24V 110V 220V 3g To 7g Ceramic Tube Ozone Generator Parts For Water Treatment
Features:
(1)Extremely low rate of ozone decay & high ozone concentration.
Ozone concentration can be around.30~86 Mg/L, which is much higher than conventional products.
(2)Domestic product-got domestic in 2008.
Air cooled for internal & external electrodes with low temperature rise of continuously working, high efficiency and stable ozone output.
(3)Low working voltage
The working voltage is only 10% of the similar products, stable capacity but with low ozone dissipated.
(4)Small in size.
It saves space effectively. The size is 1/4 smaller than similar products.
(5)Easy to maintain and install
Material:
Imported material of high pure ceramic, SS 316L of internal electrode, connections which are best anti-oxidation material for ensuring several years running.
Some studies have shown that Ozone is effective in eradicating ethylene gas produced by some fruits during ripening, thus delaying the ripening process and extending the storage life of the produce held in the same storage area.
Netech Ozone:
Netech carries a range of Ozone generators designed for this purpose, offering cost-efficient solutions to address the storage requirements and needs of small and large retailer.
Specification:
Item | Unit | CH-PTF | |||||
3GA-1 (12V,24V) | 3GA-1 (220V) | 3GA-1 (110V) | 5GA-1 (12V,24V) | 5GA-1 (220V) | 5GA-1 (110V) | ||
Ambient temperature | ℃ | 21 | 21 | ||||
Ambient humidity | % | 40 | 40 | ||||
Power | W(±10%) | 50 | 55 | ||||
Working frequency | KHz (±10%) | 15.9 | 16 | ||||
Working voltage | KV(±10%) | 2.8 | 3 | ||||
Oxygen feed flow rate | LPM | 0.5-1 | 0.5-2.5 | ||||
Ozone concentration | Mg/L | 70-49 | 72-34 | ||||
Ozone output | G/Hr | 2.1-2.9 | 2.2-5.1 | ||||
Ozone output adjustable range | % | 20~100 | 20~100 | ||||
Line power supply | V/Hz | 12V 24V 110/60 220/50 | |||||
Cooling way | / | Air cooling | |||||
Cooling fan | / | 150 | |||||
Diameter of cooling fan | mm | 120 | 120 | ||||
Diameter of gas inlet/outlet | mm | EDФ6 | |||||
Power supply dimensions | mm | 158*75*68 | 158*75*68 | ||||
ozone tube dimensions | mm | 165*95*93 | 185*95*93 | ||||
Ozone tube weight | Kg | 0.55 | 0.66 | ||||
Power supply weight | Kg | 0.6 | 0.6 |
CH-PTF6GA-1 ~7GA-1:
Item | Unit | CH-PTF | ||||||
6GA-1 (12V,24V) | 6GA-1 (220V) | 6GA-1 (110V) | 7GA-1 (12V,24V) | 7GA-1 (220V) | 7GA-1 (110V) | |||
Ambient temperature | ℃ | 26 | 26 | |||||
Ambient humidity | % | 49 | 49 | |||||
Power | W(±10%) | 80 | 90 | |||||
Working frequency | KHz (±10%) | 22.1 | 17.8 | |||||
Working voltage | KV(±10%) | 2.7 | 2.6 | |||||
Oxygen feed flow rate | LPM | 1~3 | 1~3 | |||||
Ozone concentration | Mg/L | 63-34 | 71-39 | |||||
Ozone output | G/Hr | 3.7-6.1 | 4.2-7 | |||||
Ozone output adjustable range | % | 20~100 | 20~100 | |||||
Line power supply | V/Hz | M:AC220V A:DC12V/DC24V/ AC220V/AC110V | ||||||
Cooling way | / | Air cooling | ||||||
Cooling fan | / | 150 | ||||||
Diameter of cooling fan | mm | 150 | ||||||
Diameter of gas inlet/outlet | mm | EDФ6 | ||||||
Power supply dimensions | mm | 158*75*68 | 158*75*68 | |||||
ozone tube dimensions | mm | 200*95*93 | 212*95*93 | |||||
Ozone tube weight | Kg | 0.75 | 0.82 | |||||
Power supply weight | Kg | 0.6 | 0.6 |
