220V 5g 10g 15g 20g 30g Ozone Generator Water Treatment Purification cleanion
Our ozone generator is safe, clean, and reliable, taking up less space and less equipment than many chemical treatment/storage systems;Does not require filtration after ozone cleanion;Ozone is most effective, however, by either eliminating or significantly reducing precursors in the raw water responsible.
Benefits:
1.Micro-pollutant removal and eliminates the need to add processes in the treatment stream with future regulations
2.Simultaneous Odor control with cleanion process
3.Oxidizes odor-causing compounds in the wastewater
Features:
Carbon steel sprayed with plastic housing;
Built-in PSA high purity twelve tower oxygen sieve;
Built-in of product - Air cooling Ceramic ozone tube with high frequency electric board, high ozone concentration and stable ozone capacity, long life time;
Built-in Oil-free air compressor;
Built-in Air dryer and filters. To supply cool, dry, clean air source for air compressor and PSA oxygen concentrator;
Manual control, easy operation and maintenance.
Specifications
| Item | Unit | NT-YFC5G | NT-YFC10G | NT-YFC15G | NT-YFC20G | 30NT-YFC30G |
| Oxygen flow rate | LPM | 3 | 3.5 | 5 | 8 | 10 |
| Ozone concentration | Mg/L | 48.5~52.3 | 48.5~52.3 | 49.5~51.2 | 38.9~41.7 | 53.2~56.1 |
| Ozone output | G/Hr | 5 | 10~11 | 14.8~15.4 | 18.6~20 | 32~34 |
| Power | KW | ≤0.48 | ≤0.81 | ≤0.924 | ≤1.00 | ≤1.23 |
| Current | A | 2.2 | 3.6 | 4.2 | 4.5~4.7 | 5.6±5% |
| Voltage | V | 220V/50HZ | ||||
| NW | KG | 64 | 86 | 89 | 92 | 97 |
| Size | cm | 45x50x84 | 50×66×95 | 45*93*118 | ||
Noted:
1. Above ozone capacity were tested under oxygen source
2. Net weight will be 10% different for different plug
QUALITY CONTROL
In order to ensure the best quality , every ozone generator has been strictly tested before delivery.
We promise the good performance and all parts completely
according to your needs
ABOUT US
Gold supplier--Guangzhou Netech Environmental Technology Co., Ltd ,15 years of experience in Water Treatment and Environment R&D and Engineering,
we are able to solve all your solutions in Environmental Protection and Water Treatment.
High quality guarantee
Good after-sale service
Our products are sold all over the world, you can rest assured.
