Ceramic 3g-7g Ozone Generator Spare Parts Ozone Generator Tube Power Supply

Ceramic 3g-7g Ozone Generator Spare Parts Ozone Generator Tube Power Supply

  • High Light

    ceramic ozone tube

    ,

    ozone generator tube

  • Ozone Output
    30g 50g
  • Voltage
    110V 220V
  • Time Control
    5-30mins Or Continuously
  • Ozone Output Control
    20-100%
  • Ozone Generating Way
    Corona Discharge
  • Cooling Way
    Air Cooling
  • Feature
    Isolated Power Supply Plug
  • Warranty
    1 Year
  • MOQ
    1 Set
  • Usage
    Ozone Generator Assemble
  • Material
    Ceramic
  • Place of Origin
    Guangdong China
  • Brand Name
    Netech
  • Model Number
    NT - PTF
  • Minimum Order Quantity
    1 set
  • Price
    For further discussion
  • Packaging Details
    Safe double carton package with foam inside for protection
  • Delivery Time
    2-3 days after payment confirmed
  • Payment Terms
    L/C D/A D/P T/T Western Union Credit Card/ Paypal
  • Supply Ability
    1000 sets per month

Ceramic 3g-7g Ozone Generator Spare Parts Ozone Generator Tube Power Supply

Ceramic 3g-7g Ozone Generator Tube Parts Power Supply





Imported material of high pure ceramic, SS 316L of internal electrode, connections which are best anti-oxidation material for ensuring several years running.



Features:



1. Extremely low rate of ozone decay & high ozone concentration.

Ozone concentration can be around.30~86 Mg/L, which is much higher than conventional products.



2.Domestic product-got domestic in 2008.

Air cooled for internal & external electrodes with low temperature rise of continuously working, high efficiency and stable ozone output.



3.Low working voltage

The working voltage is only 10% of the similar products, stable capacity but with low ozone dissipated.



4.Small in size.

It saves space effectively. The size is 1/4 smaller than similar products.



5. Easy to maintain and install







CH-PTF1G ~3G

Item

Unit

CH-PTF

1G                 (12V)

1G              (220V)

1G                (110V)

3GM

3GA

Ambient temperature

21.6

25

23.6

21

Ambient humidity

%

40

50

21.6

40

Power

W

≤14.4

≤15

≤15

≤50

≤80

Oxygen feed flow rate

LPM

0.3~0.5

0.3~1

0.3~1

0.5-1

Ozone concentration

Mg/L

49~40

49~30

49~30

81.6-49.2

Ozone output

G/Hr

0.88~1.2

0.88~1.8

2.4-2.95

Ozone output adjustable range

%

/

/

20~100

Line power supply

V/Hz

110/60    220/50

Cooling way

/

Air cooling

Diameter of cooling fan

mm

50*50

50*50

50*50

120

Diameter of gas inlet/outlet

mm

EDФ6

Power supply dimensions

mm

105*57*50

96*47*32

96*47*32

153×60×53

201×86×83

ozone tube dimensions

mm

125*50*50

165×90*90

Ozone tube weight

Kg

0.2

0.5

Power supply weight

Kg

0.15

0.59

0.76





CH-PTF5G ~7G

Item

Unit

CH-PTF

5GM

5GA

6GM

6GA

7GA

Ambient temperature

21

21

26

26

Ambient humidity

%

40

49

49

Power

W

≤65

≤80

≤80

≤85

≤95

Oxygen feed flow rate

LPM

0.5-2

1~3

1~3

Ozone concentration

Mg/L

72~48

64.6~36.7

70~41.2

Ozone output

G/Hr

2.16~4.76

3.9~6.6

4.20~7.4

Ozone output adjustable range

%

/

20~100

/

20~100

20~100

Line power supply

V/Hz

110/60    220/50

Cooling way

/

Air cooling

Diameter of cooling fan

mm

150

Diameter of gas inlet/outlet

mm

EDФ6

Power supply dimensions

mm

177*66*53

201*86*83

177*66*53

201*86*83

201*86*83

ozone tube dimensions

mm

185*90*90

200*90*90

212*90*90

Ozone tube weight

Kg

0.53

0.56

0.65

Power supply weight

Kg

0.59

0.76

0.59

0.76

1.1
