Adjustable Ozone Generator Parts Quartz Ozone Tube Air Purify

Adjustable Ozone Generator Parts Quartz Ozone Tube Air Purify

Products - Ozone Generator Parts
  • High Light

    Adjustable Ozone Generator Parts

    ,

    Quartz Tube Ozone Generator Parts

    ,

    Air Purify Quartz Ozone Tube

  • Name
    Ozone Quartz Tube
  • Output
    3g 5g 8g10g
  • Ozone Adjustable
    20% To 100%
  • Usage
    Air Purify And Water Treatment
  • Power Board
    Module And Adjustable
  • Place of Origin
    China
  • Brand Name
    Osunshine
  • Model Number
    CH-PSF
  • Minimum Order Quantity
    1
  • Price
    negotiate
  • Packaging Details
    Safe double carton package with foam inside for protection
  • Delivery Time
    3 to 5days
  • Payment Terms
    paypal,western union,T/T,credit card
  • Supply Ability
    1000 per weeks

Adjustable Ozone Generator Parts Quartz Ozone Tube Air Purify

  • Adjustable Ozone Generator Parts Quartz Ozone Tube Air Purify
  • Adjustable Ozone Generator Parts Quartz Ozone Tube Air Purify
  • Adjustable Ozone Generator Parts Quartz Ozone Tube Air Purify
  • Adjustable Ozone Generator Parts Quartz Ozone Tube Air Purify
  • Adjustable Ozone Generator Parts Quartz Ozone Tube Air Purify
  • Adjustable Ozone Generator Parts Quartz Ozone Tube Air Purify
Get Price Contact Now

Adjustable Ozone Generator quartz Ozone Tube Ozone Generator Parts



Adjustable Ozone Generator Parts Quartz Ozone Tube Air Purify 0

Features:

1.Ozone output 3g5g8g10g.

2. High quality quartz tube, Antioxidant connections material for ensuring several years running.

3.Module power board and adjustable power board.







Specification:



Item
Unit
CH-PSF3GM
CH-PSF5GM / CH-PSF5GA
Ambient temperature
℃
26
26
Ambient humidity
%
77
77
Power
W
50
66
Oxygen feed flow rate
LPM
2
1.5
1
0.5
2
1
0.5
Ozone concentration
Mg/L
32.9
37
39
47.2
42.5
47.3
53.4
Ozone output
G/Hr
3.95
3.3
2.34
1.42
5.1
2.83
1.6
Ozone output adjustable range
%
/
CH-PSF5GM: /
CH-PSF5GA: 20-100%
Power supply
V/Hz
220v/50hz
220v/50hz
Cooling way
/
Air cooling
Air cooling
Diameter of cooling fan
mm
150*150mm
150*150mm
Diameter of gas inlet/outlet
mm
EDФ6
EDФ6
Power supply dimensions
mm
158*73*54
CH-PSF5M: 175*66*57
CH-PSF5A: 158*75*68
ozone tube dimensions
mm
160*62*47
205*62*47
Ozone tube weight
Kg
0.282
0.381
Power supply weight
Kg
0.59
CH-PSF5M: 0.72
CH-PSF5A: 0.52
Item
Unit
CH-PSF8GA-1
CH-PSF10GA-1
Ambient temperature
℃
26
26
Ambient humidity
%
77
77
Power
W
100
110
Oxygen feed flow rate
LPM
3
2
1
3
2
1
0.5
Ozone concentration
Mg/L
45.7
48.6
57
59.7
67.3
69.2
53.4
Ozone output
G/Hr
8.23
5.8
3.42
10.74
8.1
4.15
1.6
Ozone output adjustable range
%
20-100%
20-100%
Power supply
V/Hz
220v/50hz
220v/50hz
Cooling way
/
Air cooling
Air cooling
Diameter of cooling fan
mm
150*150mm
150*150mm
Diameter of gas inlet/outlet
mm
EDФ6
EDФ6
Power supply dimensions
mm
158*75*68
158*75*68
ozone tube dimensions
mm
260*62*47
310*62*47
Ozone tube weight
Kg
0.506
0.62
Power supply weight
Kg
0.52
0.52






Adjustable Ozone Generator Parts Quartz Ozone Tube Air Purify 1
