7 - 50 G / H High Efficiency Ceramic Ozone Tube For Water Plant Air Cleaner Spare Part

7 - 50 G / H High Efficiency Ceramic Ozone Tube For Water Plant Air Cleaner Spare Part

Products - Ozone Generator Parts
  • High Light

    ozone accessories

    ,

    ozone generator tube

  • Material
    High Pure Ceramic
  • Technology
    Ozone Generator
  • Cooling Way
    Air & Water Cooling
  • Thickness
    1.70 Mm
  • Ozone Concentration
    40~70 Mg/L
  • Place of Origin
    Guangdong China
  • Brand Name
    Netech
  • Model Number
    CH-PT 7-50 G/Hr
  • Minimum Order Quantity
    1 set
  • Price
    For futher discussion
  • Packaging Details
    Safe double carton package with foam inside for protection
  • Delivery Time
    2-7 days after payment confirmed

7 - 50 G / H High Efficiency Ceramic Ozone Tube For Water Plant Air Cleaner Spare Part

  • 7 - 50 G / H High Efficiency Ceramic Ozone Tube For Water Plant Air Cleaner Spare Part
  • 7 - 50 G / H High Efficiency Ceramic Ozone Tube For Water Plant Air Cleaner Spare Part
  • 7 - 50 G / H High Efficiency Ceramic Ozone Tube For Water Plant Air Cleaner Spare Part
  • 7 - 50 G / H High Efficiency Ceramic Ozone Tube For Water Plant Air Cleaner Spare Part
Get Price Contact Now

Ozone Generator Ceramic Tube 7 - 50 g / h For Water Plant Air Cleaner Spare Part





Model:CH-PT 7-50 G/Hr

Ozone concentration: 40~70 mg/L



Advantage:

High efficiency: The narrow-gap discharge,high ozone conversion rate, low noise.
High-voltage high-frequency corona discharge.
Domestic product -- got domestic in 2008.
It is 1/4 smaller than similar products with same capacity.
The working voltage is only 10% of the similar products, stable capacity but with low ozone dissipated.
Imported material of high pure ceramic, SS 316L of internal electrode, connections which are best anti-oxidation material for ensuring several years running.



Specification:


The gas source requirements:

Item Unit CH-PT
7GM 7GA 15GA 30GA 50GA
Ambient temperature ℃ 28 21.9 22 26
Ambient humidity % 37 39 38 44
Oxygen feed flow rate LPM 1~3 3~5 7~9 15~18
Ozone concentration Mg/L 70-40 66.4~53 62~53 52~49
Ozone output G/Hr 4.2~7.2 11.9~15.9 26~28.6 46.8~52.9
Power (220V) W ≤100 ≤100 ≤190 ≤300 ≤500
Current +_10% A 0.45 0.86 1.4 1.9
Cooling way 　 Air cooling for external electrode,water cooling for internal electrode
Cooling water flow rate LPM >2
Diameter of cooling water pipe mm EDФ10
Temperature of cooling water ℃ Ambient temperature ±8℃
Diameter of cooling fan mm 1pcs Dia.150 fan 2pcs Dia.150 fan
Diameter of Gas inlet/outlet mm EDФ6 EDФ6 EDФ6 EDФ8 EDФ8
Ozone output adjust range % / 20-100 20-100
Line power supply V/Hz 110/60 220/50
Ozone tube dimensions mm 200×100×105 260×100×105 300×140×150 325×140×150
Power supply dimensions mm 177×66×53 201×86×83 125×100×95 210×146×60 210×146×60
weight of power supply KG 0.73 0.66 1.0 0.62+2 0.62+2
weight of ozone tube KG 1.12 1.38 3.76 4.2


Application:

SPA and hot tub
Water dispenser
Washer
Dishwasher
Drinking water purification
Aquaculture

Swimming pool
Ozone machine
Sewage disposal facility
and other relative fields.

7 - 50 G / H High Efficiency Ceramic Ozone Tube For Water Plant Air Cleaner Spare Part 0

7 - 50 G / H High Efficiency Ceramic Ozone Tube For Water Plant Air Cleaner Spare Part 1


7 - 50 G / H High Efficiency Ceramic Ozone Tube For Water Plant Air Cleaner Spare Part 2
