Place of Origin: | Guangdong China |
Brand Name: | Netech |
Model Number: | NT-YFC |
Minimum Order Quantity: | One unit |
---|---|
Price: | for futher discussion |
Packaging Details: | Safe double carton package with foam inside for protection |
Delivery Time: | 5-10 days after payment confirmed |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 1500 sets per month |
Gas Source: | PSA Oxygen Source | Cooled Way: | Air Cooled |
---|---|---|---|
Guarantee: | 12 Months | Ozone Capacity: | 5g / 10g / 15g / 20g / 30g |
MOQ: | One Unit | Core Parts: | Air Cooling Ozone Tube |
High Light: | water treatment ozone generator,ozone generator wastewater treatment |
Ozone Generator Water Purification For Cleaning Ozone cleanr Machine 30g
Description:
Gas source | Oxygen |
Oxygen flow rate | 3-10LPM |
Material | Ceramic tube |
Cooling | Air cooling |
Power supply | 220V 50HZ |
Commodity | Ozone air / water purifier system |
Ozone output | 5g / 10g / 15g / 20g / 30g |
Features:
1. Carbon steel sprayed with plastic housing;
2. Use PSA high purity twelve tower oxygen sieve as gas feed;
3. Use of product –Air cooling Ceramic ozone tube with high frequency electric board, high ozone concentration and stable ozone capacity, long life time;
4. Use Oil-free air compressor;
5. It has Air dryer and filters. To supply cool, dry, clean air source for air compressor and PSA oxygen concentrator;
Control panel:
Voltmeter, Ampere meter, Timer, Ozone Ampere meter, Main switch, Power supply switch, Emergency stop, working light, Power light, Alarm
Control protection:
Over current protection,Electric leakage protection, Short circuit protection, Over heat of air compressor protection,Time delay system protection
Ozone function:
1 Use ozone water to clean the fish, meat. Food: it have good cleaning effect and keep long time fresh
2 Use ozone water to clean the vegetables or fruits: it can decompose the residual pesticides or toxic chemicals.
3 Ozone water to clean the ancient rice: it can wipe off the mildew smell or carcinogens.
4 Use ozone water to clean the air .it can analyze the bacillus. Lampblack, paint and footgear smell from air or other malfeasances. and can prevent the ailment to diffuse
5 Use ozone water to wash hands or clean the dishware. cooker : it can clean and cleanr can prevent the bacillus to chiasmic contaminate
6 Use ozone water to clean the women or baby article. Towel. bedding.: it can clean and cleanr wipe off the rudimental better than cleanor
7 Use ozone water to nurse body or nurse skin: people can use it to clean the tartar. wash face to be beauty and white , can wipe off the acne or whelk and can prevent the illness from skin
8 Use ozone water to defend ill or curative: it have good curative effect of halitosis. Tooth agnail. Grey nail. hemorrhoids, vagina agnail or beriberi
9 Use ozone water to breed fish: it can clean and cleanr. Clean the water quality. In crease the active Oxygen. It is easier firm to survive and pullulate.
10 use ozone water to clean the pets : it can prevent the bacillus produce and the ailment to diffuse.
Specifications:
Item | Unit | NT-YFC5G | NT-YFC10G | NT-YFC15G | NT-YFC20G | NT-YFC30G |
Oxygen flow rate | LPM | 3 | 3.5 | 5 | 8 | 10 |
Ozone concentration | Mg/L | 48.5~52.3 | 48.5~52.3 | 49.5~51.2 | 38.9~41.7 | 53.2~56.1 |
Ozone output | G/Hr | 5 | 10~11 | 14.8~15.4 | 18.6~20 | 32~34 |
Power | KW | ≤0.48 | ≤0.81 | ≤0.924 | ≤1.00 | ≤1.23 |
Current | A | 2.2 | 3.6 | 4.2 | 4.5 - 4.7 | 5.6 ± 5% |
Voltage | V | 220V / 50HZ | ||||
NW | KG | 64 | 86 | 89 | 92 | 97 |
Size | cm | 45x50x84 | 50×66×95 | 45 * 93 * 118 |
1. Above ozone capacity were tested under oxygen source
2. Net weight will be 10% different for different plug
Our Service :
1.Reply your inquiry in 24 working hours.
2.Experienced staffs answer all your question in fluent English.
3.Customized design is avaliable.OEM&ODM are welcomed.
4.Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staffs.
5.Special discount and protection of sales area provided to our distributor.
